Leif Tent

✓ Low Environmental Impact Family Tent
✓ Made of PE material

ECO-EFFICIENCY Read more

DOWNLOADS

Technical sheet Setup Instructions

Specifications

Length	Tent: 660 x 400 cm
Height	Central: 220 cm Doors: 140 cm Walls: 125 cm
Weight	49 kg
Floor area	23 m2
Vestibule	16 m2
Length x width inner tent	395 x 380 cm
Central height inner tent	210 cm
Inner side wall height	115 cm

Outer Tent	Woven High-Density Polyethylene (HDPE) Black Fibers, White LDPE Coating on Both Side, 170gsm +/- 10 grams with up to 15% post consumer recycled materials
Inner tent	130 gsm polycotton fabric, Flame Retardant (CPAI 84-6, M1 and B2)
Groundsheet	Sewn in bathtub ground sheet made of woven PE 170 gsm +/- 10 grams
Mud flap	Woven PE 170 gsm +/- 10 grams
MOSQUITO	Polyester PVC coated
Poles	1 ridge pipe 4 m \| 2 upright poles 2,2 m \| 6 side poles 1,25 m \| 4 door poles 1,4 m
Pegs	6 T pegs (25 x 25 x 3 mm) 40cm \| 4 candy cane pegs 30 cm \| 26 o pegs 23 c
Color	Outer tent: white Inner tent: sand / cream

Winterization kit

Shade net

Upon customer request

Life span	Min. 3 years in all climates
Shelf life	Min. 5 years in normal warehouse conditions
Treatments	Core treated with UV stabilisers No harmful chemical surface treatments
Resistance to fungi	Synthetic fabric, not sensitive to fungi
Setup	Easy setup (20 min \| 3 persons)
Weight	49 kg

Doors	2 doors outer tent (130 x 140cm), 1 front and 1 back 2 doors inner tent (100 x 175cm), 1 front and 1 back
Windows	2 long side windows outer tent (360x60cm) inner tent has 2 windows of equal size 2 ventilation openings, front and back on outer tent
Ventilations	1 long ridge ventilation + 2 upper gable ventilations on inner tent
Chimney	1 heat resistant chimney reinforcement in inner and outer tent

Packing unit (P.U.)	PE bag, with separated webbing bands + handle
Content P.U.	Tent, inner tent with groundsheet, poles, accessories and hammer
QTY P.U.	1 piece
P.U. MEASUREMENTS	DIMENSIONS: 230 x 30 x 30 cm WEIGHT: 49 kg VOLUME: 0,21 m³
QTY PALLET	16 pcs per metal stackable pallet
PALLET MEASUREMENTS	DIMENSIONS: 230 x 120 x 113 cm WEIGHT: 805 kg VOLUME: 3,2 m³
LOADING	PER 20 FT DC 180 pcs unpalletized (est.) \| 160 pcs palletized PER 40 FT DC 340 pcs unpalletized (est.) \| 320 pcs palletized PER 40 FT HC 360 to 400 pcs unpalletized (est.) \| 320 pcs palletized

RECYCLED MATERIALS	Made with 15% post consumer recycled materials.
TREATMENTS	No use of phosphorus-based Flame Retardant (FR) additives. FR additives are embedded into the yarn during the manufacturing process. No chemical additives on the surface.
PACKAGING	Made from sustainable materials, designed for second life. No unnecessary single-use plastics.
TRANSPORT	Packaging, pallets and loading are optimised
DURABILITY	Made with longlasting materials to improve lifespan
REPAIR	Easy to repair. Supplied with repair kit.
SECOND LIFE USE	Designed for second life purposes
MARKING	Printing with no harmful water based ink on sustainable sticky tape.

Groundsheet

Sewn in bathtub ground sheet made of woven PE 170 gsm +/- 10 grams

Material tent

Woven High-Density Polyethylene (HDPE) Black Fibers, White LDPE Coating on Both
Side, 170gsm +/- 10 grams with up to 15% post consumer recycled materials
Flame Retardant (EN13823-A1)

Ventilation

Enhanced ventilation options thanks to large windows on both sides of the tens and ventilation opening on top.

Door opening

Entrance of 140 x 140 cm on both sides.
Vestibule of 8 sqm on both sides.

Treatments

No use of phosphorus-based Flame Retardant (FR) additives. The FR additives
are embedded into the yarn during the manufacturing process. No chemical additives on the surface.

1/5

Downloads

Technical sheet Setup Instructions
